Impact Sprinklers

HT-30P (Plastic)

Made of engineering plastic with MS heavy weight inserted in the arm to eliminate arm vibration.

Crops:

All crops irrigation compatible by overhead irrigation.
Cumin, Wheat, Mustard, Bajra, Strawberry & Garlic crops can be irrigated.

DOWNLOAD BROCHURE

Features

Specially designed for large precipitation rate and spacing.

Durable Engineering plastic Body, Arm, Nut and Tube.

Threaded brass nozzles for durability.

MS heavy weight inserted in the arm, eliminate arm vibration & good impact.

Stainless Steel Pivot Pin and springs.

Technical Specification

Connection size - 3/4'' BSP/NPT male threaded and 1'' Female threaded.

Available in 1'' BSP/NPT Female threaded.

Recommended Pressure 2.0 - 5.0 kg/cm² or 30 - 70Psi.

Recommended spacing up to 18m for higher distribution uniformity.

Trajectory Angle: 25°.

Radius coverage area is 17 mtr.
